Case study:Beekherstel Ramsbeek

From RESTORE
Jump to: navigation, search
This case study is pending approval by a RiverWiki administrator.
Approve case study



0.00
(0 votes)


To discuss or comment on this case study, please use the discussion page.


Location: 52° 4' 40", 6° 41' 26"
Edit location
Loading map...
Left click to look around in the map, and use the wheel of your mouse to zoom in and out.


Project overview

Edit project overview
Status Complete
Project web site
Themes Habitat and biodiversity, Monitoring
Country Netherlands
Main contact forename John
Main contact surname Lenssen
Main contact user ID
Contact organisation Waterschap Rijn en Ijssel
Contact organisation web site http://www.wrij.nl/
Partner organisations STOWA
Parent multi-site project

Building with Nature

This is a parent project
encompassing the following
projects
No
This case study hasn’t got a picture, you can add one by editing the project overview.

Project summary

Edit project overview to modify the project summary.


Het waterlichaam Ramsbeek behoort tot de KRW categorie “Rivieren”. Het waterlichaam behoort tot het waterlichaam type R5: langzaam stromende middenloop/benedenloop op zand. Het waterlichaam Ramsbeek is volledig in beheer bij Waterschap Rijn en IJssel. Het waterlichaam ligt in de Provincie Gelderland en valt binnen de gemeente Berkelland. Het waterlichaam, de Ramsbeek, heeft een lengte van 5,2 kilometer en een stroomgebied in Nederland van 2334 ha. De Ramsbeek heeft haar oorsprong deels in Duitsland en wordt daarnaast gevoed door de Veengoot die ontspringt nabij de Leemputten en het Zwillbrocker Venn. Het totale stroomgebied van de Ramsbeek is 4152 ha waarvan 1818 ha in Duitsland ligt. De Ramsbeek mondt uit in de Berkel. Om het peil te regelen zijn er in de Ramsbeek één regelbare stuw en zes vaste stuwen. In 2013 zijn de stuwen vispasseerbaar gemaakt of verwijderd. In het waterlichaam Ramsbeek wordt per peilvak een vast maximum streefpeil gehanteerd, als gevolg van de vaste stuwen. Het peil is afhankelijk van de bovenstroomse aanvoer. In de stuwpanden met de variabele stuwen is het peil variabel. Deze stuwen zijn in de afgelopen planperiode verwijderd in het kader van de herinrichting van de beek. Het waterlichaam 48 Ramsbeek is het gehele jaar watervoerend. Tijdens droge periodes vallen de bovenstroomse delen van de watergangen niet droog. In het stroomgebied van de Ramsbeek liggen geen RWZI’s of IBA’s.

Monitoring surveys and results

This case study hasn’t got any Monitoring survey and results, you can add some by editing the project overview.

Lessons learnt

This case study hasn’t got any lessons learnt, you can add some by editing the project overview.


Image gallery




Catchment and subcatchment

Catchment

River basin district Rijn
River basin Berkel

Subcatchment

River name -
Area category 10 - 100 km²
Area (km2) 99.24
99.24 km²
9,924 ha
Maximum altitude category Less than 100 m
Maximum altitude (m) 23
23 m
0.023 km
2,300 cm
Dominant geology Siliceous
Ecoregion Central Plains
Dominant land cover Grassland
Waterbody ID



Other case studies in this subcatchment: Beekherstel Eefsebeek, Beekherstel Leerinkbeek


Site

Name Ramsbeek
WFD water body codes
WFD (national) typology R5
WFD water body name
Pre-project morphology Actively meandering
Reference morphology Actively meandering
Desired post project morphology
Heavily modified water body Yes
National/international site designation
Local/regional site designations
Protected species present No
Invasive species present No
Species of interest
Dominant hydrology
Dominant substrate Sand
River corridor land use Grassland
Average bankfull channel width category Less than 2 m
Average bankfull channel width (m) 1
1 m
0.001 km
100 cm
Average bankfull channel depth category Less than 0.5 m
Average bankfull channel depth (m) 0.2
0.2 m
2.0e-4 km
20 cm
Mean discharge category 0.1 - 1.0 m³/s
Mean annual discharge (m3/s) 0.9
0.9 m³/s
900 l/s
Average channel gradient category more than 0.1
Average channel gradient 0.7
Average unit stream power (W/m2) 6178.41
6,178.41 W/m²


Project background

Reach length directly affected (m)
Project started 2008/2015
"2008/2015" contains a sequence that could not be interpreted against an available match matrix for date components.
Works started
Works completed 2015/12/31
Project completed
Total cost category
Total cost (k€)
Benefit to cost ratio
Funding sources

Cost for project phases

Phase cost category cost exact (k€) Lead organisation Contact forename Contact surname
Investigation and design
Stakeholder engagement and communication
Works and works supervision
Post-project management and maintenance
Monitoring



Reasons for river restoration

Mitigation of a pressure
Hydromorphology Continuity for organisms, Flow velocities, Width & depth variation
Biology Fish, Invertebrates
Physico-chemical Oxygen balance, PH, Temperature
Other reasons for the project


Measures

Structural measures
Bank/bed modifications Beschaduwing
Floodplain / River corridor Dood hout inbreng
Planform / Channel pattern
Other
Non-structural measures
Management interventions
Social measures (incl. engagement)
Other


Monitoring

Hydromorphological quality elements

Element When monitored Type of monitoring Control site used Result
Before measures After measures Qualitative Quantitative
Width & depth variation Yes Yes No No No Improvement
Flow velocities Yes Yes No No No Improvement
Substrate conditions Yes Yes No No No Improvement

Biological quality elements

Element When monitored Type of monitoring Control site used Result
Before measures After measures Qualitative Quantitative
Fish Yes Yes No No No Improvement
Invertebrates Yes Yes No No No Improvement

Physico-chemical quality elements

Element When monitored Type of monitoring Control site used Result
Before measures After measures Qualitative Quantitative
Oxygen balance Yes Yes No No No Improvement
PH Yes Yes No No No Improvement
Temperature Yes Yes No No No Improvement

Any other monitoring, e.g. social, economic

Element When monitored Type of monitoring Control site used Result
Before measures After measures Qualitative Quantitative
Concentration phosphate, Chloride and Nitrogen Yes Yes No No No Improvement


Monitoring documents



Additional documents and videos


Additional links and references

Link Description

Supplementary Information

Edit Supplementary Information
